Cummins Turbocharger 4051117 1118V90-020-720

Export Ready

Cummins Turbocharger 4051117 1118V90-020-720

Name: Cummins Turbocharger 4051117 1118V90-020-720
Brand: Komotashi
SKU: 00543
Rating: 4.8 (0 reviews)

Product Name: Turbocharger
Turbo Model: HX35W
Assembly Part No.(Assy.): 4051117
Manufacturer: Dongfeng No.49 Factory
Matching Engine: Cummins Medium-duty Diesel Engine
Application Scenarios: Medium-duty trucks, passenger coaches, construction machinery, industrial diesel generator overhaul replacement

HX35W wastegate turbocharger is manufactured by Dongfeng No.49 Factory for Cummins medium-displacement diesel engines. It compresses intake air to raise cylinder air density, improves fuel combustion efficiency and low-speed torque output, reduces fuel consumption and exhaust emissions, complies with domestic and international mainstream emission standards, and serves as premium aftermarket replacement spare parts for commercial vehicles and engineering machinery equipment.

Overview

Product Details

Manufactured strictly in accordance with Cummins and Holset original design drawings, dimensional tolerances and standardized production processes, Assy No.4051117 shares consistent structural layout, installation dimensions and boost pressure calibration parameters with interchange parts, supporting direct bolt-on installation without any modification. It effectively solves common turbo faults such as insufficient power during climbing, heavy black smoke, abnormal engine oil consumption and obvious turbo lag caused by ageing and damage.The rotor assembly undergoes ultra-precise high-speed dynamic balance testing; all finished turbochargers pass air tightness inspection, boost pressure calibration and comprehensive appearance quality check before delivery, capable of stable long-term operation under harsh working conditions including continuous medium load, frequent start-stop and high exhaust temperature environments.

Product Advantages

High-strength Materials & Stable Structure

Turbine wheel and compressor impeller adopt high-temperature resistant nickel-based alloy material, with excellent thermal fatigue resistance to adapt to the high exhaust temperature working condition of Cummins medium-displacement diesel engines
Advanced floating oil film bearing system ensures smooth rotor rotation, effectively avoids oil leakage failures, and adapts to frequent start-stop and medium-load working scenarios of road vehicles and engineering equipment
External pneumatic wastegate accurately adjusts intake boost pressure in real time, prevents engine damage caused by overboost, and brings quick low-speed power response

OEM Grade Precision Manufacturing

Overall shape, mounting hole position and boost parameters are fully consistent with original factory accessories, plug-and-play installation without pipeline transformation
High-precision dynamically balanced rotor reduces operation vibration and noise, effectively prolonging the overall service life of the turbocharger
Multiple air tightness tests eliminate oil seepage, compressor surge and abnormal exhaust noise issues

Compatibility & Supply Status

Matched Engine: Cummins Medium-duty Diesel Engine, Turbo Spec: HX35W, Assembly Number: 4051117
Production Manufacturer: Dongfeng No.49 Factory
Applicable equipment: Medium-duty trucks, highway passenger cars, wheel loaders, excavators, stationary industrial diesel generator sets
Mature Cummins medium engine aftermarket spare parts supply system, sufficient inventory and short delivery cycle
Brand-new finished products in stock, competitive unit price and flexible cooperation terms for bulk orders

Technical Specifications

Part Name	Manufacturer	Applicable Engine	Assembly No.	Turbo Model	Supporting Equipment
Turbocharger	Dongfeng No.49 Factory	Cummins Medium-duty Diesel Engine	4051117	HX35W	Medium-duty Truck, Passenger Coach, Construction Machinery, Diesel Generator Set
